32
Frost 2/2 - a medium frost ne position movement 2
Fr. Shutters.rot- a framing shutters module ne rotation (value range: 0-255)
Fr. Shutter 1 Move - a Fram. lamella 1 ne moving
Fr. Shutter 1 Swiv. - a Fram. lamella 1 ne swivelling
Fr. Shutter 2 Move - a Fram. lamella 2 ne moving
Fr. Shutter 2 Swiv.- a Fram. lamella 2 ne swivelling
Fr. Shutter 3 Move - a Fram. lamella 3 ne moving
Fr. Shutter 3 Swiv. - a Fram. lamella 3 ne swivelling
Fr. Shutter 4 Move - a Fram. lamella 4 ne moving
Fr. Shutter 4 Swiv. - a Fram. lamella 4 ne swivelling
Calibration of the eects via the control board
1. Disconnect DMX controller from the xture and enter the "Calibrate E󰀨ects" menu.
2. Use the [up arrow] and [down arrow] to nd "Pan" and touch it to enter the ne e󰀨ect adjustment screen.
3. Set desired value and save it by touching the [conrm].
4. Repeat steps 2 and 3 for next item
5. After calibrating all e󰀨ects, touch the [conrm] to save all adjusted values and reset the xture.
Calibration of the eects via the DMX controller
1. Connect DMX controller to the xture and enter the "Calibrate E󰀨ects" menu.
Calibration protocol:
E󰀨ect Mode 1 Mode 2 Mode 3
Pan channel 50 channel 34 channel 54
Tilt channel 51 channel 35 channel 55
Ef. wheel channel 52 channel 36 channel 56
Rot. Gobo Wheel channel 53 channel 37 channel 57
R. Gobo Index 1 channel 54 channel 38 channel 58
R. Gobo Index 2 channel 55 channel 39 channel 59
R. Gobo Index 3 channel 56 channel 40 channel 60
R. Gobo Index 4 channel 57 channel 41 channel 61
R. Gobo Index 5 channel 58 channel 42 channel 62
R. Gobo Index 6 channel 59 channel 43 channel 63
R. Gobo Index 7 channel 60 channel 44 channel 64
Prism 1 channel 61 channel 45 channel 65
Prism 2 channel 62 channel 46 channel 66
Zoom channel 63 channel 47 channel 67
Focus channel 64 channel 48 channel 68
Iris channel 65 channel 49 channel 69
Frost 1/1 channel 66 channel 50 channel 70
Frost 1/2 channel 67 channel 51 channel 71
Frost 2/1 channel 68 channel 52 channel 72
Frost 2/2 channel 69 channel 53 channel 73
Fr. Shutters rot. channel 70 channel 54 channel 74
Fr. Shutter 1 Move channel 71 channel 55 channel 75
Fr. Shutter 1 swiveling. channel 72 channel 56 channel 76
Fr. Shutter 2 Move channel 73 channel 57 channel 77
Fr. Shutter 2 swiveling channel 74 channel 58 channel 78
Fr. Shutter 3 Move channel 75 channel 59 channel 79
Fr. Shutter 3 swiveling channel 76 channel 60 channel 80
Fr. Shutter 4 Move channel 77 channel 61 channel 81
Fr. Shutter 4 swiveling channel 78 channel 62 channel 82
Calibrate Fr. Hysteresis
Framing Lamella 1 - a framing lamella 1 reverse movement (value range: 0-8)
Framing Lamella 2 - a framing lamella 1 reverse movement (value range: 0-8)
Framing Lamella 3 - a framing lamella 1 reverse movement (value range: 0-8)
Framing Lamella 4 - a framing lamella 1 reverse movement (value range: 0-8)
The value set for every framing lamella gives a value at which the lamella reacts to its reverse
movement promptly (without movement hysteresis).
Calibrate Colours - The menu serves for calibration of white colours in a factory. Do not change values in
the menu otherwise the menu item "Opto Corrections" will not run.
Green Corrections - The menu allows you to correct calibrated whites 2700K, 3200K, 4200K, 5600K and
