DMX protocol
1 2 3
Mode/channel
DMX
Value
Function
Type of
control
2 LED Frequency (step -126) step
3 LED Frequency (step -125) step
4 LED Frequency (step -124) step
:
125 LED Frequency (step -3) step
126 LED Frequency (step -2) step
127 LED Frequency (step -1) step
128
Selected LED Frequency (128=default)
step
129 LED Frequency (step +1) step
130 LED Frequency (step +2) step
131 LED Frequency (step +3) step
:
252 LED Frequency (step +124) step
253 LED Frequency (step +125) step
254 LED Frequency (step +126) step
255 Selected LED Frequency step
9 7 9 Colour functions
Factory display menu setting: Colour mixing mode-CMY, Dimmer
Curve-Square Law, Tungsten effect simulation-Off, Chromatic white-
Off, Light output stability-Off, Uniformity-Off
0 No function (0=default) step
To activate following functions, stop in DMX value for at least 3 seconds.
Corresponding menu items are temporarily overriden
1-39
Reserved
40-44 Colour mixing mode: CMY (DMX Mode 1 and 2 only) step
45-49 Colour mixing mode: RGB (DMX mode 1 and 2), RGBAL (DMX mode 3 only) step
50-54 Dimmer curve: Square law step
55-59 Dimmer curve: Linear step
60-79 Raw DMX proportional
Tungsten effect simulation for whites 2700K-4200K only:
80-84 Tungsten effect simulation (750W/80V): On step
85-89 Tungsten effect simulation (1000W/240V): On step
90-94 Tungsten effect simulation (1200W/240V): On step
95-99 Tungsten effect simulation (2000W/230V): On step
100-104 Tungsten effect simulation (2500W/230V): On step
105-109 Tungsten effect simulation: Off step
110-114
Save user colour (see user manual, chapter 5.1 Colour influencing functions)
step
115-119 Chromatic white: On step
120-124 Chromatic white: Off step
125-129 Light output stability On step
130-134 Light output stability Off step
135-139 Uniformity On step
140-144 Uniformity Off step
145-255 Reserved
10 8 10
0-255 CRI selection from Standard (80) to High (90+) (0=default) proportional
11 * 11
0 No function (0=default) step
1-2
Filter 4 (Medium Bastard Amber)
step
