DMX protocol
1 2 3
Mode/channel
DMX
Value
Function
Type of
control
20-24
Graphic display: On
step
25-29
Graphic display: Off
step
30-39
Reserved
step
40-44 Pan/Tilt mode: Speed step
45-49 Pan/Tilt mode: Time step
50-54 Blackout while pan/tilt moving: On step
55-59 Blackout while pan/tilt moving: Off step
60-64 Blackout while gobo wheel moving: On step
65-69 Blackout while gobo wheel moving: Off step
70-74
Fans mode: Auto
step
75-79
Fans mode: High
step
80-119
Reserved
120-124 Parking position On step
125-129 Parking position Off step
To activate following functions, stop in DMX value for at least 3 seconds.
130 - 139 Fixture reset (except pan/tilt)
140 - 149 Pan/Tilt reset step
150 - 159 Reserved step
160 - 169 Gobo wheel/effect wheel reset step
170 - 179 Reserved
180 - 189 Zoom/focus/frost/prism reset step
190 - 199 Iris /framing shutters reset step
200 - 209 Total fixture reset step
210-224
Reserved
The following RoboSpot related commands are only applicable when the RoboSpot
is connected:
225 - 229 RoboSpot enabled step
230 - 234 RoboSpot disabled - except handle faders and pan/tilt step
235 - 239 RoboSpot fully disabled step
240 Disabled "Quiet mode" step
241 - 255 Quiet mode - fan noise control from min. to max. proportional
7 * 7
Factory display menu setting: 600Hz
Select PWM output frequency of LEDs. Selected PWM frequency can be
fine adjusted in 127 steps up/down around selected PWM frequency on
the channel below. Corresponding menu item (Frequency Setup) is
temporarily overriden.
0-4
PWM frequency from Display menu (fixture utilizes PWM
step
frequency set in the display menu item Frequency Setup).
5-9 300 Hz step
10-14 600 Hz (10=default) step
15-19 1200 Hz step
20-24 2400 Hz step
25-255
Reserved (fixture utilizes PWM frequency set in the display menu item
Frequency Setup).
8 * 8
LED frequency fine adjusting
Factory display menu setting: 600Hz
Select desired PWM output frequency of LEDs on the channel above.
0-1 Selected LED Frequency step
Page 3
