Robe XT Series - DMX Protocol

8
Channel Value Function Type of control
1 Pan-movement mirrorhead 1and 4
0-255 Gradual pan mirror movement proportional
2 Tilt-movement mirrorhead 1and 4
0-255 Gradual tilt mirror movement proportional
3 Pan-movement mirrorhead 2and 5
0-255 Gradual pan mirror movement proportional
4 Tilt-movement mirrorhead 2and 5
0-255 Gradual tilt mirror movement proportional
5 Pan-movement mirrorhead 3and 6
0-255 Gradual pan mirror movement proportional
6 Tilt-movement mirrorhead 3and 6
0-255 Gradual tilt mirror movement proportional
7 Effect wheel 1
0-79 Full circle,white step
80-159 Multicolour gobo step
160-239 6 gobos with 6 colours step
240-255 Rainbow effect step
8 Effect wheel 2
0 Blackout step
1-85 Dimmer intensity (85-max.intensity) step
86-124 Full circle,white step
125-127 Reset step
128-192 Magenta,cyan,yellow step
193-255 Rotating 3-fold prism step
9 Prism rotation
0-126 Anti-clokwise rotation with decreasing speed proportional
127-128 No rotation step
129-255 Clokwise rotation with increasing speed proportional
10 Rotation of the mirrored cylinders between
mirrorhead 1/2 and 4/5
0 No rotation step
1-126 Anti-clokwise rotation with decreasing speed proportional
127-128 No rotation step
129-254 Clokwise rotation with increasing speed proportional
255 No rotation step
11 Rotation of the mirrored cylinders between
mirrorhead 2/3 and 5/6
0 No rotation step
1-126 Anti-clokwise rotation with decreasing speed proportional
127-128 No rotation step
129-254 Clokwise rotation with increasing speed proportional
255 No rotation step
4.3 DMX protocol
