Roberts R809 - Using an AC Adaptor

12
Using an AC adaptor (optional)
The AC adaptor for use with the R809 should provide 6 volts DC output
at 300mA centre pin negative (Roberts type PU6-B).
Insert the adaptor plug into the socket marked DC IN 6V on the left side
of the radio. Plug the adaptor into a standard 13A mains socket outlet.
Whenever the adaptor is used the batteries are automatically
disconnected.
The AC adaptor should be disconnected from the mains supply when
not in use.
We would recommend for economy that the R809 be used via an
AC adaptor wherever possible with battery operation for
occasional or stand-by use only.
PU6-B
INPUT 240V 50Hz
OUTPUT 6V 400mA
-
+
+ -
