43
Using an external aerial
To obtain optimum performance from this unit, especially when listen-
ing to SW an external aerial should be used. This can be a length of
wire 10 - 15 metres long connected to a 3.5mm mono jack plug which
is then inserted into the socket marked "AM EXT. ANT" located on the
left side of the radio.
MW step size switch
1. This switch located on the right side of the radio beneath the
"Rotary tuning" knob provides a means of changing the MW step
size from 9kHz to 10kHz. In Europe and most other parts of the
world set the switch to the 9kHz position. For the USA and Canada
set the switch to the 10kHz position.
