Roberts R9905 - Circuit Features; Loudspeaker; Output Power; Headphone Socket

Specifications
Power Requirements
Mains AC 230 volts, 50Hz only
Batteries 4 x LR14 (C size) for radio
2 x LR03 (AAA size) for clock/memory
Battery Life
Approx. 40hrs of listening for 4 hours a day at
normal volume using alkaline cells.
Frequency Coverage
FM 87.5-108MHz
MW 522- 1620kHz
LW 144- 281kHz
Circuit Features
Loudspeaker 92mm 8ohms
Output Power 850 mW into 4ohms
Headphone socket 3.5mm dia
Aerial System FM Telescopic aerial
MW Built-in Ferrite aerial
LW Built-in Ferrite aerial
ROBERTS RADIO LIMITED
PO BOX 130
MEXBOROUGH
SOUTH YORKSHIRE
S64 8YT
The Company reserves the right to amend the specification without notice.
