To Test Thermostat
WARNING: DO NOT SHORT (JUMPER) ACROSS TERMINALS OF GAS VALVE OR SYS-
TEM CONTROL TO TEST OPERATION. THIS WILL DAMAGE THE THERMOSTAT AND VOID
YOUR WARRANTY.
CAUTION: DO NOT SWITCH SYSTEM TO COOL IF THE TEMPERATURE IS BELOW 50°F (10°C). THIS
CAN DAMAGE THE AIR CONDITIONING SYSTEM AND CAUSE PERSONAL INJURY
.
1. Place the COOL/OFF/HEAT
switch into the COOL position
2. Press the c button until the temperature
setting is at least 3 degrees below the room temperature. The air
conditioning system should turn on within a few seconds.
NOTE: W
HILE IN THE
C
OOL MODE
, (
COOL AND HEAT FOR SINGLE STAGE HEAT PUMP SYSTEM
)
ONCE THE THERMO
-
STAT TURNS THE SYSTEM OFF
,
A BUILT
-
IN DELAY KEEPS THE COMPRESSOR FROM TURNING ON FOR ABOUT
5
MINUTES
.
T
HIS PROTECTS THE COMPRESSOR
. N
O ADDITIONAL TIME DELAY RELAY
(
DELAY ON BREAK
)
IS NECESSARY
. T
O OVERRIDE
THE
5-
MINUTE DELAY FOR INSTALLATION
,
PRESS
RESET. T
HIS WILL ERASE THE DELAY AS WELL AS ALL PROGRAMMING
.
3. Put the COOL-OFF-HEAT switch into
the OFF position. The air conditioning
system should turn off. The fan may
continue to run for a short period of time.
4. Put the COOL-OFF-HEAT switch
into the HEAT position.
5. Press the button until the temperature setting is at least
3 degrees above room temperature. The heating system should turn
on. The fan may not turn on immediately, depending upon the fan
delay built into the furnace.
6. Put the COOL-OFF-HEAT switch
into the OFF position. The heating
system should turn off. Once again,
the fan may have a delay.
7. Put the AUTO-ON switch
to the ON position. The blower
fan should turn on.
8. Put the AUTO-ON switch
to the AUTO position. The blower
fan should turn off.
9
