WIRING DIAGRAMS
10
T
ypical 3H/2C or 2H/1C Heat Pump System
FAN RELA
Y
EMERGENCY
HEA
T RELA
Y
COMPRESSOR
RELA
Y
COMPRESSOR
RELA
Y 2
COOL REVERSING
VAL
VE
HEAT REVERSING
VAL
VE
AUXILIARY
HEA
TRELA
Y
(HOT)
T
ypical 2H/2C System: 2 T
ransformers
COMPRESSOR
RELA
Y
F
AN RELA
Y
HEA
T RELA
Y
HEA
T RELA
Y 2
COMPRESSOR
RELA
Y 2
REMOVE JUMPER
(HOT)
(HOT)
11
13
