Robertshaw RS10420T - Table of Contents

INSTALLATION MANUAL
Table of Contents Page
Installation Location 3-4
Thermostat Quick Reference 5
Wiring 6-7
Wiring Diagrams 8-10
Installer Setup 11-16
Programming 17-20
Setting Up WiFi Connection and App 21
Specications
Temperature Display Range ........................ 32°F to 99°F (0°C to 40°C)
Temperature Control Range ....................... 41°F to 90°F (5°C to 32°C)
Load Rating ................................................ 1 amp per terminal, 1.5 amp maximum
all terminals combined
Differential .................................................. Heating is adjustable from 0.2°to2.0°
Cooling is adjustable from 0.2° to2.0°
Power Source ............................................. 18 to 30 VAC, NEC Class II, 50/60 Hz for hardwire
Operating Ambient Temperature ................. 32°F to +105°F (0°C to +41°C)
Operating Humidity .................................... 90% non-condensing maximum
Dimensions ................................................. 4.7”W x 4.4”H x 1”D
