Robertshaw RS10420T User Manual

Getting to know your thermostat
1 Fan Buttons
2 Next Step Buttons
3 Set Time Buttons
4 Program Buttons
5 Menu Buttons
6 System Buttons
7 Set-Point Buttons
1 Days of the week and time
2 Indicates the current room temperature
3 Displays the user selected
set-point temperature
4 Hold is displayed when thermostat
program is overridden.
5 System Operation Indicators: If these icons
are ashing, there is a 5-minute delay for
compressor protection.
6 Programmable Time Periods: Residential
uses 4 time periods - WAKE, RETURN,
LEAVE and SLEEP.
7 Program Menu Options:Shows different
options during programming.
Sun Mon Tue Wed Thu Fri Sat
WAKE LEAVE RETURN SLEEP
HOLD
Auto
On
IAQ
Technician
Setup
NextStep
Set Time
Clean
NextZone
Set Schedule
Hold
PreviousStep
Run Schedule
Menu
Done
Heat
Off Cool
Auto
Em.heat
FAN
SYSTEM
Set At
Sun Mon Tue Wed Thu Fri Sat
WAKE LEAVE RETURN SLEEP
AM
PM
Technician
Setup
NextStep
Set Time
Clean
NextZone
Set Schedule
Hold
PreviousStep
Run Schedule
Menu
Done
Heat
Off Cool
Auto
Em.heat
SYSTEM
Set At
Auto
On
IAQ
HOLD
FAN
THERMOSTAT QUICK REFERENCE
