Day&Night IP Camera
4.2. Specifications
Models
Day & Night
Power
DC 12V, 1A or DC 5V, 1A
Processors
RISC CPU, hardware video processing and
compression.
Network interface
Ethernet 10BaseT/100BaseTX, Auto-MDIX, RJ-45
Wireless interface
IEEE 802.11n 90 - 150 Mbps
IEEE 802.11g 6 - 54 Mbps
IEEE 802.11b 1 - 11 Mbps
Transmit power: 14.5dBm typically @ 802.11g
17.5dBm typically @ 802.11b
Receiver sensitivity:
54Mbps: Typical -73dBm @ 10%
PER
11Mbps: Typical -86dBm @ 10% PER
Antenna gain: 0.01 dBi
Image sensor
RGB VGA 1/4 inch CMOS
Day and night separate sensors
Automatic exposure control, automatic white balance,
automatic gain control, automatic brightness control.
PIR sensor
Effective distance – 7 meters.
Light sensitivity
0.2 Lux ( IR LED off )
0 Lux (with 10 meters IR LED on)
Automatically turn on the IR LED on low light
environment.
Lens
3.2 mm, F2.0, viewing angle: 60.3°, fixed iris.
focus range: 30 cm to infinity
Day and night separate lens
Buttons
One reset button, to factory default settings
One WPS button for automatic WiFi setup
Indicators
One LED for Internet connection status indication
One LED for Ethernet connection indication
One LED for SD card recording indication
Video compression
H.264, baseline profile level 3.1
Video streaming
Separate frame rate/resolution/bandwidth settings for
PC and mobile.
Video settings
Resolution: VGA(640x480), QVGA(320x240),
QQVGA(160x120)
47
