Robomow RK1000 User Manual

34 35
• Wires leading to and from an island should be fastened with the
same peg
Set the Perimeter Wire
clockwise around the
obstacle, otherwise
the mower will drive
into the Perimeter
Island or won’t be
able to mow the
area around it
properly.
TIPS
Protect Soft Obstacles
Objects such as ower beds, ponds, or small trees must be
protected by setting Perimeter Islands.
Soft Obstacles
3
Keep min. 1.2 m (4 ft) between
islands; if obstacles are closer
together, use one island.
If the distance between an island and the
perimeter wire is lower than 1.2m (4 ft), make
the obstacle part of lawn’s edge.
Perimeter Wire position
Perimeter Wire

Robomow RK1000 Specifications

General

Cutting Width	21 cm
Cutting Height	20-100 mm
Battery Type	Lithium-Ion
Battery Capacity	4.3 Ah
Max Lawn Size	1000 m²
Slope Capability	45%
Noise Level	60 dB
Battery Voltage	18 V
Charging Time	60-120 minutes
Working Time	60 minutes
