Roca BCH-10 - BCH-20 (230.3.50) Power Diagram

35
Power diagram
BCH - 20, 230.3.50
IO: M1: M2: M3: R1: R2:
JOBSITE INSTALLATION COMPRESSOR INDOOR FAN OUTDOOR FAN INDOOR HEATER 10/15 kW DUCT ELECTRIC HEATER 20/30 kW
I-1308/g
BCH-20, 230.3.50
SEE DIAGRAM
RC-20-220/30-220
(03) (04) (06)(05) (07)
L3 L1
(1) (1)
230V,3 , 50 Hz,
~
IO
(01) (02)
L1
L1
L3
L3
Q1
30 m A
Q2
50 A
L2
L2
M1
1 2
3
4
(6)
L1 L3
X1/...
10 mm Cu.
2
K6
L2
5
6
M2
M 3
~
1L1
F4
(8)
13 21
14 22
OFF ON
3L2 5L3
K2
(14)
135 246
2L1 4L2 6L3
M3
M 3
~
1L1
F5
(15)
13 21
14 22
OFF ON
3L2 5L3
K3
(13)
135 246
2L1 4L2 6L3
10 kW-6 15 kW-10
mm Cu
2
L1
L2 L3
Q4
10 kW - 32 A 15 kW - 50 A
L1
L2 L3
Q 3
30 mA
K4
(4)
1
2
3
5
6
4
R1
10 kW-6 15 kW-10
mm Cu
2
10 kW-6 15 kW-10
mm Cu
2
L1
L2 L3
Q8
10 kW - 32A 15 kW - 50A
L1
L2 L3
Q 7
30 mA
K15
1
2
3
5
6
4
L1
L2 L3
L1
L2 L3
Q 5
30 mA
Q6
10 kW - 32 A 15 kW - 50 A
K12
(5)
1
2
3
5
6
4
R2
(5)
THE COMPONENTS INCLUDED IN THESE BOXES ARE NOT SUPPLIED BY THE MANUFACTURER. THE COMPONENTS INCLUDED IN THESE BOXES ARE STANDARD ACCESSORIES SUPPLIED BY THE MANUFACTURER.
