Roca BCH-10 - Physical Data

6
reaching it. Also it increases the efficiency of the system.
Coils
Of large heat transfer area, made of copper tubes and
aluminum fins.
They are located inside the casing and are therefore pro-
tected from being damaged during transport and installation.
Fans indoor and outdoor fan
Centrifugal type with direct drive motor.
These fans develop sufficient pressure for the installation of
ducts and optional accessories.
Casing
Built of steel sheet with aluminum-zinc protection, with
primer and powder epoxy finish to allow its installation out-
doors.
Supplementary electric heaters
Of the air exposed wires type that allow a rapid heat dissipa-
tion, avoiding the thermal inertia that could affect com-
ponents.
BCH-7 BCH-10 BCH-12 BCH-15 BCH-20 BCH-25 BCH-30
Quantity 1 1 1 1 1 1 1
Nominal power kW 2.8 4.3 4.7 5.3 6.9 9 10
Power supply V.ph.Hz. 230.1.50
Quantity 1 1 1 1 1 1 1
Tubes length x height 5 x 18 5 x 21 5 x 21 5 x 21 5 x 27 5 x 24 5 x 24
Fins per inch 12 12 14 12 14 14 14
Face area m
2
0.32 0.41 0.51 0.51 0.65 0.7 0.89
Tubes diameter mm (Inch) 9.52 (3/8") 9.52 (3/8") 9.52 (3/8") 9.52 (3/8") 9.52 (3/8") 9.52 (3/8") 9.52 (3/8")
Quantity 1 1 1 1 1 1 1
Tubes length x height 3 x 18 4 x 21 4 x 21 4 x 21 4 x 27 3 x 24 4 x 24
Fins per inch 12 12 12 12 12 12 12
Face area m
2
0.22 0.25 0.37 0.37 0.47 0.61 0.61
Tubes diameter mm (Inch) 9.52 (3/8") 9.52 (3/8") 9.52 (3/8") 9.52 (3/8") 9.52 (3/8") 9.52 (3/8") 9.52 (3/8")
Quantity 1 1 1 1 1 1 1
Turbine diameter mm 270 320 320 320 320 320 320
Turbine width mm 270 240 240 240 320 240 320
Nominal power kW 0.58 0.99 0.99 0.99 1.1 1.1 1.5
Nominal motor rpm 950 950 950 950 950 950 1 420
Power supply V.ph.Hz. 230.1.50 230.1.50 230.1.50 230.1.50
Quantity 1 1 1 1 1 1 1
Turbine diameter mm 240 270 320 320 320 320 320
Turbine width mm 240 200 240 240 240 240 240
Nominal power kW 0.38 0.54 0.95 0.95 0.99 1.1 1.1
Nominal motor rpm 950 950 950 950 950 1 410 1 410
Power supply V.ph.Hz. 230.1.50 230.1.50 230.1.50 230.1.50
R-22 refrigerant charge kg 2.95 4.2 4.5 4.75 7.5 5.9 7
Approximation nett weight kg 193 223 271 275 340 355 412
Approximation gross weight kg 219 257 311 315 370 395 462
Dimensions with standard packing cm 132x132x65 136x139x71 155x160x71 155x160x71 155x160x87 176x180x78 176x220x78
Indoor
fan
motor
Model
Compressor
Outdoor
coil
Indoor
coil
Outdoor
fan
motor
230.3.50
400.3.50
Physical data
230.3.50
400.3.50
230.3.50
400.3.50
230.3.50
400.3.50
230.3.50
400.3.50
230.3.50
400.3.50
230.3.50
400.3.50
230.3.50
400.3.50
230.3.50
400.3.50
230.3.50
400.3.50
230.3.50
400.3.50
230.3.50
400.3.50
