Roca BCH-7 - General Dimensions; BCH-7, 10 Dimensions

25
Model A B C D E F G H I J K L M N O P Q S T U V
BCH-7 471 1200 1250 1156 78 376 290 302 80 362 35 86 262 376 550 214 436 214 362 154 154
BCH-10 549 1250 1300 1206 78 376 396 268 78 362 75 109 293 461 517 291 442 192 362 132 143
General dimensions mm
Note:
1- The solid line arrows indicate the standard air inlets and outlets. The
dotted line arrows show inlet and outlet arrangements that can be
performed on the jobsite.
2- If a filter with rack is to be fitted in the air intake, refer to the accessory's
brochure for the dimensions.
BCH-7, 10
EF G H U
B
A
POQ
22 O.D. DRAIN
CONNECTIONS
OPTIONAL OUTDOOR
AIR OUTLET
OPTIONAL INDOOR
AIR INTAKE
OPTIONAL OUTDOOR
AIR INTAKE
OPTIONAL INDOOR
AIR OUTLET
B
D
B
C
INDOOR
AIR OUTLET
INDOOR AIR
INTAKE
OUTDOOR
AIR INTAKE
OUTDOOR
AIR OUTLET
DETAIL "Z"
IF S N V
T
K
T
K
J
K
20
D.12 (4)
22
DETAIL "Z"
MINIMUM
CLEARANCE
300
MINIMUM
CLEARANCE
500
M
L
OUTDOOR SIDE VIEW
INDOOR SIDE VIEW
ELECTRICAL
CONNECTIONS
