Roca BCH-7 - Air Filter Details

44
Height
Width
Depth
Height
Width
Depth
356
370
100
375
450
110
Air filter
Of the cleanable type, with open cell polyurethane foam filter
mat.
Can be adapted to either the evaporator or condenser side.
Once attached the filter will exceed the conditoner's outer
dimensions by 100 mm.
General dimensions mm
426
470
100
445
550
110
Model
BCH -7 & 10 BCH -12, 15 & 20
Shipping
dimensions
Filter
dimensions
A
B
C
Note: With the BCH-20 unit this accessory can be connected only in the
indoor air return.
1 300
1 500
2 000
2 500
3 000
3 500
4 000
4 500
5 000
5 500
6 000
-
BCH -7 & 10 BCH -12, 15 & 20
Flow rate m
3
/h
mm WG
Pa mm WG
Pa
0.82
1.06
1.35
1.65
2.00
2.30
2.70
3.00
8.0
10.3
13.0
16.0
19.6
22.5
26.4
29.4
-
-
-
-
-
-
-
-
-
-
-
-
-
Filters pressure drop (mm WG)
0.64
0.80
1.20
1.60
2.10
2.60
3.20
6.20
7.80
11.70
15.60
20.50
25.40
31.30
A
C
B
