Figure 4 if you intend to work with the software handshake or without any handshake.
Cables with the above mentioned pin mappings work with most connecting equipment
installed in commercially available computers. However, depending on your particular
computer configuration, you may require a cable with a different pin mapping.
Check with the technical documentation of your computer equipment.
To obtain a suitable cable, contact your service representative.
