RK3288 Hardware Design Guide
 Dual-channel input for front and rear camera
 Dual-channel MIPI-CSI2 interface with 4-lane per channel
 8/10/12 bits standard DVP interface
 Maximum 5Mpixel for front camera
 Maximum 13Mpixel for rear camera with high-performance ISP
 Video display
 Dual-panel display with 2 separately interface
 Maximum resolution is 4Kx2K
 CABC support to decrease interface power
 Dual channel 8/10bits LVDS
 Dual channel MIPI-DSI
 HDMI2.0 to support maximum 4Kx2K display
 Optional eDP1.1 interface
Memory Interface
 Nand Flash Interface
 Dual-channel , 8bits per channel
 Compatible with all of SLC/MLC/TLC Nand Flash, including DDR Nand
 Embedded 60bits hardware ECC
 8 chip selects to support more device
 eMMC Interface
 Compatible with eMMC4.5 standard
 8bits data width
 Support DDR-50,SDR-100
 DDR interface
 Dual channel 64bits interface
 Support DDR3/DDR3L/LPDDR2/LPDDR3
Rich Connectivity
 3 SD/MMC/SDIO interface, compatible with SD3.0,SDIO3.0 and MMC4.5
 One 8-channels I2S/PCM interface, One 8-channels SPDIF interface
 One USB2.0 OTG , Two USB2.0 Host
