Pg 14 Pg 15
MACHINE INSTALLATION
CONNECTING TO MAIN WATER SUPPLY
The R NINE ONE is preset at the factory to use the supplied 1.9 litre
water reservoir.
To connect the R NINE ONE machine to mains water supply, use
the steel braided water hose provided and ensure the following
instructions are adhered to:
1. Use a certied plumber to complete the installation and
ensure that the installation meets local authority standard and
regulations in all cases.
2. Line pressure exceeding 4 bars should be limited with the use of a
pressure regulating valve on the water feed line.
3. Use a shut off valve to isolate the water supply to the machine.
4. If you are drawing water from a non pressurised system (ie. from a
remote water supply tank, not mains pressurised) t a non return
valve to the end of the water supply hose to ensure that the line
pressure is maintained at all times.
5. Use an in line lter to ensure the water supply of the machine
is of the highest quality - ask your plumber what he would
recommend.
6. Once the mains installation is complete it will be necessary to
switch the machine from tank to water supply.
See page 20. Water source settings.
DIGITAL DISPLAY GLOSSARY
–
SCREEN 1
1. 1 cup symbol
2.
2 cups symbol
3.
Rocket symbol: press to
move between screens
4.
Hot water symbol: press
to switch between on/off
5.
symbol indicates the
coffee boiler is heating
6.
symbol indicates the
coffee boiler is not heating
NB. It is normal for the
machine to switch between
and symbols.
Machine temperature is
always indicated above this
symbol.
7.
symbols
indicates the selected
pressure prole being used
8.
symbol indicates manual
mode
9.
symbol recalls last saved
manual prole
1
2
3
4
5
7
6
8
9
