4 Align the wall plate (3) with the anchors, insert the lag screws (18) through the
holes in the wall plate assembly, then tighten the lag screws only until they are
firm against the wall plate.
CAUTION: Avoid potential injuries or property damage!
DO NOT over-tighten the lag screws (18).
You’ll need
Lag screw 18 (Qty.4)
Pencil
Drill
1/2" socket wrench
Level
Hammer
3/8" masonry
drill bit
Tape
Template (5)
Wall plate 3
Concrete anchor 22
(Qty.4)
