RocketFish RF-SBM102 - STEP 7 B - Back-mounted threaded inserts

15
RF-SBM102
STEP 7B - Back-mounted threaded inserts
1 Attach the soundbar arm brackets (02 and 03) to your soundbar using two screws (18, 19, 20, or 21) and
washers (22 or 23).
2Tighten the screws (L) to secure the arms in place.
You’ll need
Screws
Washers
Phillips screwdriver
18 M4 × 10 mm screw (2)
19 M4 × 16 mm screw (2)
20 M5 × 16 mm screw (2)
21 M6 × 16 mm screw (2)
22 M4/M5 washer (2)
23 M6 washer (2)
