RocketFish RF-SBM102 - STEP 7 C - Bottom-mounted threaded inserts

16
STEP 7C - Bottom-mounted threaded inserts
Align the bottom brackets (04) with your soundbar mounting holes and attach using two screws (18, 19, 20, or 21) and
washers (22 or 23). If the supplied screws are too long for your soundbar, use the 2.5 mm spacers (15).
You’ll need
Washers
Screws
Phillips screwdriver
18 M4 × 10 mm screw (2)
19 M4 × 16 mm screw (2)
20 M5 × 16 mm screw (2)
21 M6 × 16 mm screw (2)
22 M4/M5 washer (2)
23 M6 washer (2)
04 Bottom
bracket (2)
15 2.5 mm spacer (4)
