RocketFish rf-tvmfm02 User Manual

11
Need help? Call 800-620-2790
RF-TVMFM02 TV Wall Mount
Step 4 Adjust the viewing angle
When the television is mounted onto the arm assembly and secured, the assembly can be adjusted to make the
TV level.
1 Loosen the two screws on the arm assembly using the 5/32" hex key (S).
2 Adjust the TV ± 6° either clockwise or counter-clockwise.
3 Retighten the screws.
You’ll need
S (1)

RocketFish rf-tvmfm02 Specifications

Power

Operating voltage	3V (Battery: CR2025)
Standby current	1.2μA

Operating Environment

Operating temperature	14° ~ 122°F (-10° ~ 50°C)
Transmitting angle	30°
Maximum operating distance	32.8 ft. (10 m)

Frequency

Carrier frequency	38.1 KHZ

Physical Characteristics

Dimensions	2.6 × 1.2 × 0.3" (6.7 × 3.1 × .7 cm)
Weight	0.4 oz (12 g)
Wavelength	940 nm
