RocketFish rf-tvmfm02 User Manual

5
Need help? Call 800-620-2790
RF-TVMFM02 TV Wall Mount
Hard ware
Package contents: hardware
Make sure you have all the hardware necessary to assemble your new TV wall mount:
Label Hardware Qty.
C 2
D 2
E 2
F 4
G 4
H 8
I 4
J 4
K 4
L 4
Concrete
anchor
Lag bolt washer
5/16" × 2 3/4"
(7.9 × 69.8 mm) lag bolt
M4 × 12 mm screw
M4 × 30 mm
screw
M4/M5 washer
M4/M5 spacer
M5 × 12 mm screw
M5 × 30 mm
screw
M6 × 12 mm screw
Label Hardware Qty.
M 4
N 4
O 4
P 4
Q 4
R 1
S 1
T 1
U 5
M6 × 20 mm
screw
M6 × 35 mm
screw
M6/M8 washers
M6/M8 spacers
M8 × 40 mm screw
3/16" hex key
5/32" hex key
Cap screw
Cable ties (8"/20.5 cm
nylon)
10 20 30 40 50 60 70 80 90 100mm
1234in

RocketFish rf-tvmfm02 Specifications

Power

Operating voltage	3V (Battery: CR2025)
Standby current	1.2μA

Operating Environment

Operating temperature	14° ~ 122°F (-10° ~ 50°C)
Transmitting angle	30°
Maximum operating distance	32.8 ft. (10 m)

Frequency

Carrier frequency	38.1 KHZ

Physical Characteristics

Dimensions	2.6 × 1.2 × 0.3" (6.7 × 3.1 × .7 cm)
Weight	0.4 oz (12 g)
Wavelength	940 nm
