RF-TVMFM02 TV Wall Mount
Assembly instructions
Step 1 Install the TV bracket
Option 1: Installing for a flat mounting surface
1 Align the TV bracket (A) with the screw holes on the back of the TV.
2 Place an M4/M5 washer (H) or an M6/M8 washer (O) over each of the four screw holes in the TV bracket, then
insert an M4 screw (F), M5 screw (J), or M6 screw (L or M) through each washer.
3 Tighten the screws until they are snug against the TV bracket. Do not over tighten.
You’ll need
H (4) O (4) F (4) J (4) L (4) M (4)
Phillips screwdriver
OR
OR
OR
OR

RocketFish rf-tvmfm02 Specifications

Power

Operating voltage	3V (Battery: CR2025)
Standby current	1.2μA

Operating Environment

Operating temperature	14° ~ 122°F (-10° ~ 50°C)
Transmitting angle	30°
Maximum operating distance	32.8 ft. (10 m)

Frequency

Carrier frequency	38.1 KHZ

Physical Characteristics

Dimensions	2.6 × 1.2 × 0.3" (6.7 × 3.1 × .7 cm)
Weight	0.4 oz (12 g)
Wavelength	940 nm
