6
External Connections
LCD Display
1. Playing chord indication
2. Volume level display
3. TONE, RHYTHM or demo SONG
4.
Digital display for song, rhythm and tone number
5.
Tempo value of rhythm and song (bpm)
6. Metronome for rhythm and song
7. Mode Indicator 1
8. Key Indicator
9. Mode Indicator 2
USB AUX PHONES DCIN
1
2
3 4
MICMicroSD
5 6
1
43
5
6
9
7
2
8
1. Micro SD Card Slot (MP3 Playback)
2. USB Input (MP3 Playback)
3. MIC Input (Electret type)
4. AUX Input
5. Headphone Output
6. DC Input
