Rockwell Automation Publication 1769-IN088A-EN-P - February 2011 149
I/O Memory Mapping Chapter 3
Input Data
- Local:1:I AB:1769_OF8C:I:0
+ Local:1:I.Fault DINT Binary
+ Local:1:I.CombinedStatus SINT Binary
Local:1:I.Ch0Status BOOL Decimal
Local:1:I.Ch1Status BOOL Decimal
Local:1:I.Ch2Status BOOL Decimal
Local:1:I.Ch3Status BOOL Decimal
Local:1:I.Ch4Status BOOL Decimal
Local:1:I.Ch5Status BOOL Decimal
Local:1:I.Ch6Status BOOL Decimal
Local:1:I.Ch7Status BOOL Decimal
+ Local:1:I.ModuleStatus SINT Binary
Local:1:I.PowerFail BOOL Decimal
+ Local:1:I.Ch0_1Status SINT Binary
Local:1:I.Ch0OverRange BOOL Decimal
Local:1:I.Ch0UnderRange BOOL Decimal
Local:1:I.Ch0InHold BOOL Decimal
Local:1:I.Ch0OpenWire BOOL Decimal
Local:1:I.Ch1OverRange BOOL Decimal
Local:1:I.Ch1UnderRange BOOL Decimal
Local:1:I.Ch1InHold BOOL Decimal
Local:1:I.Ch1OpenWire BOOL Decimal
+ Local:1:I.Ch2_3Status SINT Binary
Local:1:I.Ch2OverRange BOOL Decimal
Local:1:I.Ch2UnderRange BOOL Decimal
Local:1:I.Ch2InHold BOOL Decimal
Local:1:I.Ch2OpenWire BOOL Decimal
Local:1:I.Ch3OverRange BOOL Decimal
Local:1:I.Ch3UnderRange BOOL Decimal
