Rockwell Automation Publication 1769-IN088A-EN-P - February 2011 151
I/O Memory Mapping Chapter 3
Output Data
Ch2_3
Status
Ch3
OpenWire
Ch3
InHold
Ch3
Under
Range
Ch3 Over
Range
Ch2
OpenWire
Ch2
InHold
Ch2
Under
Range
Ch2
Over
Range
Ch4_5
Status
Ch5
OpenWire
Ch5
InHold
Ch5
Under
Range
Ch5 Over
Range
Ch4
OpenWire
Ch4
InHold
Ch4
Under
Range
Ch4
Over
Range
Ch6_7
Status
Ch7
OpenWire
Ch7
InHold
Ch7
Under
Range
Ch7 Over
Range
Ch6
OpenWire
Ch6
InHold
Ch6
Under
Range
Ch6
Over
Range
(1) Bit positions left blank in table are always set to 0.
Local:1:O AB:1769_OF8C:O:0
+ Local:1:O.Ch0Data INT Decimal
+ Local:1:O.Ch1Data INT Decimal
+ Local:1:O.Ch2Data INT Decimal
+ Local:1:O.Ch3Data INT Decimal
+ Local:1:O.Ch4Data INT Decimal
+ Local:1:O.Ch5Data INT Decimal
+ Local:1:O.Ch6Data INT Decimal
+ Local:1:O.Ch7Data INT Decimal
+ Local:1:O.AlarmUnlatch INT Binary
Local:1:O.Ch0OverRangeUnlatch BOOL Decimal
Local:1:O.Ch0UnderRangeUnlatch BOOL Decimal
Local:1:O.Ch1OverRangeUnlatch BOOL Decimal
Local:1:O.Ch1UnderRangeUnlatch BOOL Decimal
Local:1:O.Ch2OverRangeUnlatch BOOL Decimal
Local:1:O.Ch2UnderRangeUnlatch BOOL Decimal
Local:1:O.Ch3OverRangeUnlatch BOOL Decimal
Local:1:O.Ch3UnderRangeUnlatch BOOL Decimal
Local:1:O.Ch4OverRangeUnlatch BOOL Decimal
Local:1:O.Ch4UnderRangeUnlatch BOOL Decimal
Local:1:O.Ch5OverRangeUnlatch BOOL Decimal
Local:1:O.Ch5UnderRangeUnlatch BOOL Decimal
Local:1:O.Ch6OverRangeUnlatch BOOL Decimal
Local:1:O.Ch6UnderRangeUnlatch BOOL Decimal
Local:1:O.Ch7OverRangeUnlatch BOOL Decimal
Local:1:O.Ch7UnderRangeUnlatch BOOL Decimal
Tag
Name
Bit Indicates This
(1)
76543210
