60 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 3 I/O Memory Mapping
Define To Select Make these bit settings
15 14…11 10 9 8 7…4 3 2 1 0
Input Filter Selection 60 Hz
0000
50 Hz 0001
28.5 Hz 0010
300 Hz
0011
360 Hz 0100
Enable Interrupt Enable 1
Disable 0
Enable Process
Alarm Latch
Enable 1
Disable 0
Enable Process Alarms Enable 1
Disable 0
Enable Channel Enable 1
Disable 0
Define Indicate this These bit settings
15…11 10 9 8 7…4 3 2 1 0
Input Range Select -10…+10V dc
0000
0…5V dc 0001
0…10V dc
0010
4…20 mA 0011
1…5V dc 0100
0…20 mA
0101
Input Data Select Raw/Proportional
Counts
000
Engineering Units 0 0 1
Scaled for PID 0 1 0
Percent Range 0 1 1
