Rockwell Automation Publication 2711R-UM001H-EN-E - April 2021 119
Appendix C
Install and Replace Components
Chapter Objectives This chapter shows how to install, replace, or upgrade various components of
the PanelView 800 terminals.
• microSD memory card
• USB flash drive
• Battery replacement
microSD Memory Card The microSD memory card can be inserted in the following locations on the
PanelView 800 terminals.
microSD memory card slot
2711R-T4T 2711R-T7T 2711R-T10T
