88 Rockwell Automation Publication 2711R-UM001H-EN-E - April 2021
Chapter 4 Secure the Terminal
To exit Protected mode, the running application has to be stopped and
unloaded successfully. To unload an application, go to the File Manager
configuration screen on the terminal and press the Stop Application button.
After the boot-up process and the terminal loads a startup
application.
Yes
An application is loaded. Yes
An application is unloaded successfully and the terminal
displays a terminal configuration screen.
No
IMPORTANT
The Stop Application button is only available in firmware revision 3.011
onwards.
Terminal Operations and Protected Mode State
Operation Terminal in Protected Mode
File Manager
Copy Alarm HistoryRecipe
Controller Settings
Main
Delete
Copy
Run
Stop Application
Set As Startup
Source: To:
Internal
Internal
Startup Application
Reset
PV800_App1
PVcApplication1
To Next Page
Loading...
