Rockwell Automation Publication 1769-IN023C-EN-P - January 2022 7
CompactLogix 5370 L3 Controller Installation Instructions
Specifications
Additional Resources
These documents contain additional information concerning related products from Rockwell Automation.
You can view or download publications at rok.auto/literature
.
Attribute
1769-L30ER, 1769-L30ER-NSE, 1769-L30ERK, 1769-L30ERM, 1769-L30ERMK, 1769-L33ER, 1769-L33ERK, 1769-L33ERM,
1769-L33ERMK, 1769-L36ERM, 1769-L37ERM, 1769-L37ERMK, 1769-L38ERM, 1769-L38ERMK
Voltage Ranges Backplane: 500 mA at 5.0V DC, 225 mA at 24.0V DC
Power Dissipation 4.5 W max
Panel Mounting Screw Type 1.1…1.8 N•m (10…16 lb•in) - use M4 or #8 screws
Wire Type, Ethernet
RJ45 connector according to IEC 60603-7, 2 or 4 pair Category 5e minimum cable according to TIA 568 B.1 or Category 5 cable
according to ISO/IEC 24702
Temperature, Operating
• IEC 60068-2-1 (Test Ad, Operating Cold)
• IEC 60068-2-2 (Test Bd, Operating Dry Heat)
• IEC 6068-2-14 (Test Na, Operating Thermal Shock)
0 °C < Ta < 60 °C (32 °F < Ta < 140 °F)
Temperature, Surrounding Air, Max 60 °C (140 °F)
Resource Description
CompactLogix 5370 L3 Controller User Manual, publication 1769-UM021
Provides information on how to install, configure, program, and use CompactLogix controllers.
Ethernet Reference Manual, publication ENET-RM002
Describes basic Ethernet concepts, infrastructure components, and infrastructure features.
UL Standards Listing for Industrial Control Products, publication CMPNTS-SR002
Assists original equipment manufacturers (OEMs) with construction of panels, to help ensure that they
conform to the requirements of Underwriters Laboratories.
Industrial Components Preventive Maintenance, Enclosures, and Contact Ratings
Specifications, publication IC-TD002
Provides a quick reference tool for Allen-Bradley industrial automation controls and assemblies.
Safety Guidelines for the Application, Installation, and Maintenance of Solid-state
Control, publication SGI-1.1
Designed to harmonize with NEMA Standards Publication No. ICS 1.1-1987 and provides general
guidelines for the application, installation, and maintenance of solid-state control in the form of
individual devices or packaged assemblies incorporating solid-state components.
Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1
Provides general guidelines for installing a Rockwell Automation industrial system.
Product Certifications website, rok.auto/certifications
Provides declarations of conformity, certificates, and other certification details.
