40 Rockwell Automation Publication 1756-UM004C-EN-P - June 2021
Chapter 3 Connect Redundant EtherNet/IP Adapters
Figure 10 - Redundant 1756-EN4TR Adapters in Star Topology with a Single Switch
Logix5575
Redundancy Module
PRI COM OK
OKFORCE SDRUN
R
U
N
R
E
M
P
R
O
G
R
1756-EN4TR pair
1756-EN4TR or
1756-EN2T
