Rockwell Automation Publication 1756-UM004C-EN-P - June 2021 5
Preface
About This Publication
This manual describes how you can use ControlLogix® EtherNet/IP™
communication modules with a Logix 5000™ controller and communicate with
various devices on the Ethernet/IP network.
Use this manual if you program applications that use EtherNet/IP networks
with these Logix 5000 controllers:
• CompactLogix™ controller
• ControlLogix controller
Conventions
Be sure to understand these concepts and tools:
• FactoryTalk® Linx
•Logix Designer
• ControlFLASH Plus™
• HMIs
• SNMP tools
Download Firmware, AOP,
EDS, and Other Files
Download firmware, associated files (such as AOP, EDS, and DTM), and access
product release notes from the Product Compatibility and Download Center at
rok.auto/pcdc
.
Summary of Changes
This manual was revised to add or update the information that is listed in this
table.
Topic Page
ControlLogix EtherNet/IP Specifications 10
Simple Network Management Protocol 13
How to Determine if the Module is in Explicit Protected Mode 19
Redundant PRP Architecture with Redbox Switches 43
Diagnostic Web Pages 50
