Rockwell Automation Allen-Bradley ControlLogix 1756-EN2F User Manual

10 Rockwell Automation Publication 1756-UM004C-EN-P - June 2021
Chapter 1 ControlLogix EtherNet/IP Network Device Overview
Table 3 - ControlLogix EtherNet/IP Data Specifications
(1)
Cat. No.
Produced/Consumed Tags
Socket Services
Duplicate IP Detection
(starting revision)
Number of Multicast Tags,
Max
(2)
Unicast Available in
RSLogix 5000 Software
1756-EN2F
32
Version 16.03.00 or later Yes
All Revisions
1756-EN2T Version 16.03.00 or later Yes
1756-EN2TP Version 24.00.00 or later Yes
1756-EN2TR Version 17.01.02 or later Yes
1756-EN3TR Version 18.02.00 or later Yes
1756-EN4TR Version 24.00.00 or later Yes
1756-ENBT Version 16.03.00 or later No Revision 3.3
1756-EWEB N/A Yes Revision 2.2
(1) Includes the K conformal coating catalog numbers and the XT extreme environment catalog numbers.
(2) Each controller can send a maximum of 32 multicast produced tags to one single consuming controller. If these same tags are sent to multiple consumers, the maximum number is 31.
Table 4 - ControlLogix EtherNet/IP Specifications
(1)
Cat. No.
Firmware
Revision
RSLogix 5000
Software Version
RSLinx Software
Version
Packet Rate Capacity (packets/
second)
(2)
Support for
Extended
Environment
(3)
Integrated Motion on
the EtherNet/IP
Network Axes
I/O HMI/MSG
1756-ENBT Any 8.02.00 or later 2.30 or later 5000 900 No N/A
1756-EN2F
2.x 15.02.00 or later
2.51 or later
10,000
2000 No
N/A
3.6 or later
18.02.00 or later
(4)
25,000
(5)
Up to 8 axes
supported
(5)
1756-EN2T
2.x or earlier 15.02.00 or later
2.51 or later
10,000
2000 No
N/A
3.6 or later
18.02.00 or later
(4)
25,000
(5)
Up to 8 axes
supported
(5)
1756-EN2TXT
2.x 15.02.00 or later
2.51 or later
10,000
2000 Yes
N/A
3.6 or later
18.02.00 or later
(4)
25,000
(5)
Up to 8 axes
supported
(5)
1756-EN2TP Any
24.00.00 or later
(4)
4.10 or later
25,000
(5)
2000 No
Up to 8 axes
supported
(5)
1756-EN2TPXT 10.x or later 24.00.00 or later 4.10 or later
25,000
(5)
2000 Yes
Up to 8 axes
supported
(5)
1756-EN2TR
2.x 17.01.02 or later 2.55 or later 10,000
2000 No
N/A
5.x or later
18.02.00 or later
(4)
2.56 or later
25,000
(5)
Up to 8 axes
supported
(5)
1756-EN2TRXT 5.028 or later 20.01.00 or later 2.56 or later
25,000
(5)
2000 Yes
Up to 8 axes
supported
(5)
