Rockwell Automation Allen-Bradley POINT I/O B Series User Manual

10 POINT I/O Field Potential Distributor Modules
Publication 1734-IN059G-EN-P - December 2018
Wire the Module
ATTENTION: If you connect or disconnect wiring while the field-side power is
on, an electrical arc can occur. This could cause an explosion in hazardous
location installations. Be sure that power is removed or the area is
nonhazardous before proceeding.
NC = No connection
Chas gnd = Chassis ground
C = Common
V = Supply
NC
Chas gnd
C
V
NC
C
V
Chas gnd
