POINT I/O Field Potential Distributor Modules 13
Publication 1734-IN059G-EN-P - December 2018
Specifications
General Specifications
Attribute Value
Terminal base screw torque 0.6 Nm (7 lb-in.)
Module location Between I/O modules in 1734 system
Breaks power bus
Indicators None
POINTBus current Pass through
Power consumption None
Power dissipation None
Thermal dissipation None
Isolation voltage (continuous-voltage
withstand rating)
50 V continuous
Tested @ 2600V DC for 60 s
Input voltage rating 12V DC, 24V DC nom
10…28.8V DC range
120V AC, 240V AC nom
Input current, max 10 A
Field power bus supply voltage 264V AC max,
12V DC, 24V DC, 10…28.8V DC range
120V AC, 240V AC, 50/60 Hz
Field power bus supply current, max 10 A
Dimensions (HxWxD), approx. 76.2 x 25.4 x 133.4 mm
(3.00 x 1.00 x 5.25 in.)
Weight 0.12 kg (0.27 lb)
Wiring category
(1)
(2)
(1)
Use this conductor category information for planning conductor routing as described in Industrial Automation Wiring
and Grounding Guidelines, publication 1770-4.1.
(2)
Use this Conductor Category information for planning conductor routing as described in the appropriate System Level
Installation Manual.
1 – on power ports
Wire size 0.25…2.5 mm² (22…14 AWG) solid or stranded copper
wire rated at 75 °C (167 °F) or greater
1.2 mm (3/64 in.) insulation max
Enclosure type rating None (open-style)
North American temp code T4A
ATEX temperature code T4
