Rockwell Automation Publication 20P-TD001K-EN-P - January 2021 33
PowerFlex DC Drive and Field Controller Technical Data
Frame B Armature Voltage Feedback Circuit Terminal Block Location
Frame C Armature Voltage Feedback Circuit Terminal Block Location
Frame D Armature Voltage Feedback Circuit Terminal Block Location
Top of Drive
Shown with terminals jumpered for
internal armature voltage feedback.
1A1
(C)
A1 1A2
(C)
A2
1A1
(C)
A1 1A2
(C)
A2
Bottom of Drive
Shown with terminals jumpered for
internal armature voltage feedback.
Bottom of Drive, Left Side
Shown with terminals jumpered for
internal armature voltage feedback.
