Rockwell Automation Publication 20P-TD001K-EN-P - January 2021 49
PowerFlex DC Drive and Field Controller Technical Data
460V AC Input Drives
Frame
Drive Current
Rating Code
DC Amps
AC Line
Amps
Bussmann Mersen
Ferrule FWP Type North American FWP Type Ferrule A70QS Type
North American A70P / A70QS
Type
A
4P1 4.1 3.3 FWP-10A14F FWP-10B A70QS10-14F A70P10-4
6P0 6 4.9 FWP-10A14F FWP-10B A70QS10-14F A70P10-4
010 10 8.2 FWP-20A14F FWP-20B A70QS20-14F A70P25-4
014 14 11.4 FWP-25A14F FWP-25B A70QS25-14F A70P25-4
019 19 15.5 FWP-25A14F FWP-25B A70QS25-14F A70P25-4
027 27 22.1 FWP-40A22F FWP-40B A70QS40-22F A70QS40-4
035 35 28.6 FWP-63A22F FWP-60B A70QS63-22F A70QS60-4
045 45 36.8 FWP-80A22F FWP-80B A70QS80-22F A70QS80-4
052 52 42.5 FWP-80A22F FWP-80B A70QS80-22F A70QS80-4
073 73 59.6
—
FWP-100A
—
A70QS100-4K
086 86 70.3 FWP-150A A70QS150-4K
100 100 81.7 FWP-175A A70QS175-4K
129 129 105.4 FWP-175A A70QS175-4K
B
167 167 136.4 FWP-300A A70QS300-4
207 207 169.1 FWP-350A A70QS350-4
250 250 204.3 FWP-400A A70QS400-4
330 330 269.6 FWP-600A A70QS600-4K
412 412 336.6 FWP-600A A70QS600-4
575V AC Input Drives
Frame
Drive Current Rating
Code
DC Amps AC Line Amps
Bussmann Mersen
North American FWP Type North American A70QS Type
B
067 67.5 55.1 FWP-100A A70QS100-4
101 101.3 82.7 FWP-175A A70QS175-4K
135 135 110.3 FWP-225A A70QS225-4
270 270 220.6 FWP-450A A70QS450-4
405 405 330.9 FWP-600A A70QS600-4K
