50 Rockwell Automation Publication 20P-TD001K-EN-P - January 2021
PowerFlex DC Drive and Field Controller Technical Data
Frame A and B Armature DC Output Fuses
Armature DC output fuses are externally mounted for frame A and B drives and must be sourced separately. These fuses are required on four
quadrant drives only, but highly recommended on two quadrant drives. See Fuse Code FS2 in PowerFlex DC Drives Frame A and B Fuse
Information on page 48
.
230V AC Input Drives
Frame
Drive Current
Rating Code
DC Amps
AC Line
Amps
Bussmann Mersen
Ferrule FWP Type North American FWP Type Ferrule A70QS Type
North American A70P /
A70QS Type
A
7P0 7 5.7 FWP-15A14F FWP-15B A70QS16-14F A70P15-4
9P0 9 7.4 FWP-20A14F FWP-20B A70QS20-14F A70P20-4
012 12 9.8 FWP-25A14F FWP-25B A70QS25-14F A70P25-4
020 20 16 FWP-40A14F FWP-40B A70QS40-14F A70QS40-4
029 29 24 FWP-63A22F FWP-60B A70QS63-22F A70QS60-4
038 38 31 FWP-80A22F FWP-80B A70QS80-22F A70QS80-4
055 55 45 – FWP-125A – A70QS125-4K
073 73 60 – FWP-150A – A70QS150-4K
093 93 76 – FWP-200A – A70QS200-4K
110 110 90 – FWP-225A – A70QS250-4
B
146 146 119 – FWP-300A – A70QS300-4
180 180 147 – FWP-350A A70QS350-4
218 218 178 – FWP-450A – A70QS450-4
265 265 217 – FWP-600A – A70QS600-4K
360 360 294 – FWP-700A – A70QS700-4
434 434 355 – FWP-900A – A70P900-4
460V AC Input Drives
Frame
Drive Current
Rating Code
DC Amps
AC Line
Amps
Bussmann Mersen
Ferrule FWP Type North American FWP Type Ferrule A70QS Type
North American A70P /
A70QS Type
A
4P1 4.1 3.3 FWP-10A14F FWP-10B A70QS10-14F A70P10-4
6P0 6 4.9 FWP-15A14F FWP-15B A70QS16-14F A70P15-4
010 10 8.2 FWP-20A14F FWP-20B A70QS20-14F A70P20-4
014 14 11.4 FWP-30A14F FWP-30B A70QS32-14F A70P30-4
019 19 15.5 FWP-40A14F FWP-40B A70QS40-14F A70QS40-4
027 27 22.1 FWP-63A22F FWP-60B A70QS63-22F A70QS60-4
035 35 28.6 FWP-80A22F FWP-70B A70QS80-22F A70QS70-4
045 45 36.8 FWP-100A22F FWP-90B – A70QS90-4
052 52 42.5 FWP-100A22F FWP-100B – A70QS100-4
073 73 59.6 – FWP-150A – A70QS150-4K
086 86 70.3 – FWP-175A – A70QS175-4K
100 100 81.7 – FWP-200A – A70QS200-4K
129 129 105.4 – FWP-250A – A70QS250-4
B
167 167 136.4 – FWP-350A – A70QS350-4
207 207 169.1 – FWP-400A – A70QS400-4
250 250 204.3 – FWP-500A – A70QS500-4K
330 330 269.6 – FWP-700A – A70QS700-4
412 412 336.6 – FWP-800A – A70QS800-4
