Rockwell Automation Publication 20P-TD001K-EN-P - January 2021 51
PowerFlex DC Drive and Field Controller Technical Data
Field Controller Frames A and B AC Input Line Fuses
AC input line fuses are externally mounted for frame A and B drives and must be sourced separately.
PowerFlex DC Drive Frame A and B Field Circuit Fuses
Field circuit fuses are internally mounted and provided with the drive. See Fuse Code FS3 in PowerFlex DC Drives Frame A and B Fuse
Information on page 48
. Also, see PowerFlex DC Drive Frame A Field AC Input Line Fuses Location on page 52 and PowerFlex DC Drive Frame
B Field AC Input Line Fuses Location on page 53
for fuse locations.
575V AC Input Drives
Frame
Drive Current
Rating Code
DC Current [A]
AC Line Current
[A]
Bussmann Mersen
North American FWP Type North American A70P / A70QS Type
B
067 67.5 55.1 FWP-125A A70QS125-4K
101 101.3 82.7 FWP-200A A70QS200-4K
135 135 110.3 FWP-250A A70QS250-4
270 270 220.6 FWP-600A A70QS600-4K
405 405 330.9 FWP-800A A70QS800-4
Cat. No.
Frame
Size
DC Amps AC Line Amps
Bussman Mersen
Ferrule
FWP Type
North American FWP
Type
Ferrule
A70QS Type
North American
A70P / A70QS Type
23PFCx017
A
17 14 FWP-25A14F FWP-25B A70QS25-14F A70P25-4
23PFCx060 60 49 FWP-80A22F FWP-80B A70QS80-22F A70QS80-4
23PFCx120 120 98
—
FWP-150A
—
A70QS150-4K
23PFCx245
B
245 201 FWP-300A A70QS300-4
23PFCx365 365 299 FWP-400A A70QS400-4
23PFCx570 570 467 FWP-600A A70QS600-4
230V AC Input Drives
Frame
Drive Current
Rating Code
Field Amps Type Quantity Bussmann Mersen SIBA
A
7P0
10
6 x 32 mm 2 FWH-016A6F E085449 70 125 40.16
9P0
012
020
029
038
055
073
14093
110
B
146
20 10 x 38 mm 2 FWC-25A10F A60Q25-2 60 033 05.25
180
218
265
360
434
