Rockwell Automation Publication 20P-TD001K-EN-P - January 2021 65
PowerFlex DC Drive and Field Controller Technical Data
Approximate Dimensions – PowerFlex DC Drives (continued)
Frame D Dimensions - Right Side and Front Views
1250
(49.2)
436.5
(17.2)
Lifting Flange
157.5
(6.2)
144
(5.7)
208
(8.2)
792
(31.2)
42
(1.7)
32
(1.3)
80.5
(3.2)
10.5
(0.4)
10
(0.4)
252.5
(10.0)
134
(5.3)
437.5
(17.2)
22.6
(0.9)
44.5
(1.8)
44.5
(1.8)
269.5
(10.6)
100
(4.0)
27.8
(1.1)
44.5
(1.8)
704 (27.7)
174
(6.9)
358 (14.1)
544 (21.4)
60
(2.4)
454.5
(18.0)
100
(4.0)
30
(1.2)
25
(1.0)
44.5
(1.8)
146
(5.7)
60
(2.4)
25
(1.0)
44.5
(1.8)
30
(1.2)
PE C D PE C D
Dimensions are shown in mm and (in.)
Dimensions of terminals U, V, and W are the same.
134 mm (5.3 in.) C and D terminals are installed on 460V AC input, 800 Hp and 900 Hp, 575V AC input, 1000 Hp, and 690V AC input,
1100, 1200, 1250, and 1,400 Hp drives only. All other frame D ratings have 100 mm (4.0 in.) C and D terminals.
