Rockwell Automation Publication 20P-TD001K-EN-P - January 2021 67
PowerFlex DC Drive and Field Controller Technical Data
Frame D - 230V AC Input Drive Weights
Frame D - 460V AC Input Drive Weights
Frame D - 575V AC Input Drive Weights
Frame D - 690V AC Input Drive Weights
Drive w/ND Rating Code
Weight, kg (lb)
Regenerative Drives Non-regenerative Drives
Drive Drive and Packaging Drive Drive and Packaging
875
203 (447.5) 281 (619.5) 152 (335.1) 230 (507.1)
1K0
Drive w/ND Rating Code
Weight, kg (lb)
Regenerative Drives Non-regenerative Drives
Drive Drive and Packaging Drive Drive and Packaging
830
202 (445.3) 280 (617.3) 152 (335.1) 230 (507.1)
996
1K1
215 (474.0) 293 (646.0) 165 (363.8) 243 (535.7)1K3
1K4
Drive w/ND Rating Code
Weight, kg (lb)
Regenerative Drives Non-regenerative Drives
Drive Drive and Packaging Drive Drive and Packaging
810
198 (436.5) 276 (608.5) 148 (326.3) 226 (498.2)
1K0
1K2 215 (474.0) 293 (646.0) 165 (363.8) 243 (535.7)
1K3 222 (489.4) 300 (661.4) 172 (379.2) 250 (551.2)
1K6 241 (531.3) 319 (703.3) 191 (421.1) 269 (593.0)
Drive w/ND Rating Code
Weight, kg (lb)
Regenerative Drives Non-regenerative Drives
Drive Drive and Packaging Drive Drive and Packaging
678
198 (436.5) 276 (608.5) 148 (326.3) 226 (498.2)
791
904 200 (440.9) 278 (612.9) 150 (330.7) 228 (502.7)
1K0 202 (445.3) 280 (617.3)
152 (335.1) 230 (507.1)
1K1
215 (474.0) 293 (646.0)
1K2 165 (363.8) 243 (535.7)
1K4
241 (531.3) 319 (703.3)
172 (379.2) 250 (551.2)
1K5 191 (421.1) 269 (593.0)
