Rockwell Automation Publication 20P-TD001K-EN-P - January 2021 7
PowerFlex DC Drive and Field Controller Technical Data
Product Selection
IP00/IP20, NEMA/UL Type Open
All drives are rated 150% overload for 60 seconds, 200% for 3 seconds.
200…240V AC, Three-Phase Drives
Drive Output Rating - 230V AC Input
Regenerative Drives Cat. No. Frame Size
Normal Duty kW Normal Duty Hp Amps
1.2 1.5 7 20P41AB7P0RA0NNN
A
1.5 2 9 20P41AB9P0RA0NNN
2.2 3 12 20P41AB012RA0NNN
3.7 5 20 20P41AB020RA0NNN
5.5 7.5 29 20P41AB029RA0NNN
7.5 10 38 20P41AB038RA0NNN
11 15 55 20P41AB055RA0NNN
15 20 73 20P41AB073RA0NNN
18.5 25 93 20P41AB093RA0NNN
22 30 110 20P41AB110RA0NNN
30 40 146 20P41AB146RA0NNN
B
37 50 180 20P41AB180RA0NNN
45 60 218 20P41AB218RA0NNN
56 75 265 20P41AB265RA0NNN
75 100 360 20P41AB360RA0NNN
93 125 434 20P41AB434RA0NNN
112 150 521 20P41AB521RA0NNN
C
149 200 700 20P41AB700RA0NNN
186 250 875 20P41AB875RA0NNN
D
224 300 1050 20P41AB1K0RA0NNN
380…480V AC, Three-Phase Drives
Drive Output Rating - 460V AC Input Non-regenerative Drives Regenerative Drives
Frame
Size
Normal Duty kW Normal Duty Hp Amps Cat. No. Cat. No.
1.5 2 4.1 20P21AD4P1RA0NNN 20P41AD4P1RA0NNN
A
2.2 3 6 20P21AD6P0RA0NNN 20P41AD6P0RA0NNN
3.7 5 10 20P21AD010RA0NNN 20P41AD010RA0NNN
5.5 7.5 14 20P21AD014RA0NNN 20P41AD014RA0NNN
7.5 10 19 20P21AD019RA0NNN 20P41AD019RA0NNN
11 15 27 20P21AD027RA0NNN 20P41AD027RA0NNN
15 20 35 20P21AD035RA0NNN 20P41AD035RA0NNN
18.5 25 45 20P21AD045RA0NNN 20P41AD045RA0NNN
22 30 52 20P21AD052RA0NNN 20P41AD052RA0NNN
30 40 73 20P21AD073RA0NNN 20P41AD073RA0NNN
37 50 86 20P21AD086RA0NNN 20P41AD086RA0NNN
45 60 100 20P21AD100RA0NNN 20P41AD100RA0NNN
56 75 129 20P21AD129RA0NNN 20P41AD129RA0NNN
75 100 167 20P21AD167RA0NNN 20P41AD167RA0NNN
B
93 125 207 20P21AD207RA0NNN 20P41AD207RA0NNN
112 150 250 20P21AD250RA0NNN 20P41AD250RA0NNN
149 200 330 20P21AD330RA0NNN 20P41AD330RA0NNN
187 250 412 20P21AD412RA0NNN 20P41AD412RA0NNN
224 300 495 20P21AD495RA0NNN 20P41AD495RA0NNN
C
298 400 667 20P21AD667RA0NNN 20P41AD667RA0NNN
