PowerFlex DC Drive and Field Controller Technical Data
Stand-alone Regulator Catalog Numbers
Conformally coated circuit boards are provided with the following catalog numbers.
373 500 830 20P21AD830RA0NNN 20P41AD830RA0NNN
D
447 600 996 20P21AD996RA0NNN 20P41AD996RA0NNN
552 700 1162 20P21AD1K1RA0NNN 20P41AD1K1RA0NNN
597 800 1328 20P21AD1K3RA0NNN 20P41AD1K3RA0NNN
671 900 1494 20P21AD1K4RA0NNN 20P41AD1K4RA0NNN
500…600V AC, Three-Phase Drives
Drive Output Rating - 460V AC Input
Non-regenerative Drives
Cat. No.
Regenerative Drives Cat.
No.
Frame
Size
Normal Duty kW Normal Duty Hp Amps
37 50 67.5 20P21AE067RA0NNN 20P41AE067RA0NNN
B
56 75 101.3 20P21AE101RA0NNN 20P41AE101RA0NNN
75 100 135 20P21AE135RA0NNN 20P41AE135RA0NNN
149 200 270 20P21AE270RA0NNN 20P41AE270RA0NNN
224 300 405 20P21AE405RA0NNN 20P41AE405RA0NNN
298 400 540 20P21AE540RA0NNN 20P41AE540RA0NNN
C
373 500 675 20P21AE675RA0NNN 20P41AE675RA0NNN
447 600 810 20P21AE810RA0NNN 20P41AE810RA0NNN
D
597 800 1080 20P21AE1K0RA0NNN 20P41AE1K0RA0NNN
671 900 1215 20P21AE1K2RA0NNN 20P41AE1K2RA0NNN
746 1000 1350 20P21AE1K3RA0NNN 20P41AE1K3RA0NNN
932 1250 1688 20P21AE1K6RA0NNN 20P41AE1K6RA0NNN
690V AC, Three-Phase Drives
Drive Output Rating - 460V AC Input
Non-regenerative Drives
Cat. No.
Regenerative Drives Cat.
No.
Frame
Size
Normal Duty kW Normal Duty Hp Amps
298 400 452 20P21AF452RA0NNN 20P41AF452RA0NNN
C
373 500 565 20P21AF565RA0NNN 20P41AF565RA0NNN
447 600 678 20P21AF678RA0NNN 20P41AF678RA0NNN
D
552 700 791 20P21AF791RA0NNN 20P41AF791RA0NNN
597 800 904 20P21AF904RA0NNN 20P41AF904RA0NNN
671 900 1017 20P21AF1K0RA0NNN 20P41AF1K0RA0NNN
746 1000 1130 20P21AF1K1RA0NNN 20P41AF1K1RA0NNN
820 1100 1243 20P21AF1K2RA0NNN 20P41AF1K2RA0NNN
932 1250 1413 20P21AF1K4RA0NNN 20P41AF1K4RA0NNN
1044 1400 1582 20P21AF1K5RA0NNN 20P41AF1K5RA0NNN
230V/460V AVC Input Regulators 575V/690V AVC Input Regulators
Field Amps
Cat. No. Cat. No.
23PMD4 23PMF4 40
23PMD7 23PMF7 70
23PAMP
(1)
(1) Gate Amplifier - used with all voltage classes of the Stand-Alone Regulator. The Stand-Alone Regulator and Gate Amplifier are currently
sold through Rockwell Automation Drive Systems only. Consult the factory for availability.
23PAMP
(1) (1)
380…480V AC, Three-Phase Drives (Continued)
Drive Output Rating - 460V AC Input Non-regenerative Drives Regenerative Drives
Frame
Size
Normal Duty kW Normal Duty Hp Amps Cat. No. Cat. No.
