Rockwell Automation Micro810 Series User Manual

12 Micro810 12 Point Programmable Controllers
Publication 2080-IN006A-EN-P - September 2010
Isolation voltage 250V (continuous),
Reinforced
Insulation Type, I/O
to Aux and
Network, Inputs to
Outputs.
Type tested for 60 s
3250V DC, I/O to
Aux and Network,
Inputs to Outputs
250V (continuous), Reinforced Insulation
Type, I/O to Aux and Network, Inputs to
Outputs
Type tested for 60 s at 720V DC, Inputs to
Aux and Network, 3250V DC Outputs to
Aux and Network, Inputs to Outputs
50V (continuous),
Reinforced
Insulation Type, I/O
to Aux and
Network, Inputs to
Outputs
Type tested for 60 s
at 720V DC, I/O to
Aux and Network,
Inputs to Outputs
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and
Grounding Guidelines, publication 1770-4.1
.
Non-isolated AC Inputs (2080-LC10-12AWA)
Attribute Value
On-state voltage, nom 120/240 V AC
On-state voltage, min 79 V AC
On-state voltage, max 265 V AC
Off-state voltage, max 40 V AC
Operating frequency, nom 50/60 Hz
Input impedence 423.7 kΩ
Operating frequency 47…63 Hz
DC Inputs (2080-LC10-12QWB, -12QBB, -12DWD) (Inputs 0 through 3)
Attribute Non-isolated, shared with analog inputs Isolated
Voltage category 24V DC sink/source
On-state voltage, nom 12/24V DC
On-state voltage, min 9.8V DC
On-state voltage, max 28.8V AC
Off-state voltage, max 5V DC
Off-state current, max 0.5 mA 1.5 mA
On-state current, min 0.75 mA @ 10.8V DC
1.0 mA @ 15 V DC
1.8 mA @ 10.8V DC
2.7 mA @ 15 V DC
On-state current, nom 1.7 mA @ 24V DC 6 mA @ 24V DC
On-state current, max 2.1 mA @ 28.8 V DC 7.5 mA @ 28.8 V DC
General (2080-LC10-12AWA, 2080-LC10-12QWB, 2080-LC10-12QBB,
2080-LC10-12DWD )
Attribute 2080-LC10-12AWA 2080-LC10-12QWB 2080-LC1012DWD 2080-LC10-12QBB
