Micro810 12 Point Programmable Controllers 13
Publication 2080-IN006A-EN-P - September 2010
Nominal impedance 14.1 kΩ 3.74 kΩ (isolated)
IEC input compatibility Type 1 Type 3
Analog Inputs (2080-LC10-12QWB, -12QBB, -12DWD) (Inputs 4 through 7)
Attribute Value
Input type DC voltage
Input voltage range 0…10V DC
Input voltage, max 26.4V DC
Value of LSB 2.5 mV
Input resolution 10-bit
Smoothing None, smoothing
Overall accuracy 5% of full-scale (2% with calibration)
(25…55 °C)
(77…131 °F)
Noise rejection 50/60 Hz
Common mode rejection 40 dB, DC to 60 Hz with Smoothing filter
Nominal impedance 14.1 kΩ (non-isolated)
DC Output (2080-LC10-12QBB)
Attribute Value
User supply voltage, min 10 V DC
User supply voltage, max 26.4V DC
On-state voltage drop 1V @ max load current
2.5V @ max surge current
Current ratings 0.5A @ 55 °C max
1.0A @ 30 °C max
1.0 mA min
Surge current, peak 4.0 A
Surge current, max duration 10 ms
Turn-on- time, max 0.1 ms
Turn-off time, max 0.1 ms
DC Inputs (2080-LC10-12QWB, -12QBB, -12DWD) (Inputs 0 through 3)
Attribute Non-isolated, shared with analog inputs Isolated
