Rockwell Automation PanelView Plus Series User Manual

Publication 2711P-UM001I-EN-P - December 2008 189
Terminal Connections Chapter 7
DeviceNet Connections
2711P-RN10C DeviceNet Module for 400 and 600 Terminals
2711P-RN10H DeviceNet Module for 700 to 1500 Terminals
WARNING
Do not connect or disconnect any communication cable with
power applied to this device or any device on the network. An
electrical arc could cause an explosion in hazardous location
installations. Be sure that power is removed or the area is
nonhazardous before proceeding.
I/O Status Indicator
MOD Status Indicator
NET Status
Indicator
Red
White
Shield
Blue
Black
MOD Status Indicator
I/O Status Indicator
NET Status
Indicator
Red
White
Shield
Blue
Black
