PowerFlex 753 Drive (P_PF753)
Start and Stop
Commands -
Operator keeps
Control in Program
mode
Check to keep the drive Start, Stop,
and Jog (if used) commands with
the Operator, even if the instruction
is in Program mode.
Clear this checkbox to have control
of the drive Start, Stop, and Jog
follow Instruction mode.
Engineering
Maintenance
(Code E)
Cfg_OperKeep.1
Start and Stop
Commands -
Program keeps
Control in Operator
mode
Check to keep control of the drive
Start and Stop commands with the
Program, even if the instruction is in
Operator mode.
IMPORTANT: The Program cannot
Jog the drive, even if Jogging is
enabled.
Clear this checkbox to have control
of the drive Start, Stop, and Jog
follow Instruction mode.
Cfg_ProgKeep.1
Forward and Reverse
Commands -
Operator keeps
Control in Program
mode
Check to keep control of the drive
Forward and Reverse commands, if
used, with the Operator, even if the
instruction is in Program mode.
Clear this checkbox to have control
of the drive Forward and Reverse
commands follow the Instruction
mode.
Cfg_OperKeep.2
Forward and Reverse
Commands -
Program keeps
Control in Operator
mode
Check to keep control of the drive
Forward and Reverse commands (if
used) with the Program, even if the
instruction is in Operator mode.
Clear this checkbox to have control
of the of the drive Forward and
Reverse commands follow the
Instruction mode.
Cfg_ProgKeep.2
Operator ‘Stop’
command available
in any mode
Check (= 1) so that the OCmd_Stop
has priority and is accepted at any
time regardless of instruction mode.
Clear this checkbox (= 0) so that the
OCmd_Stop works only in Operator
or Maintenance mode.
IMPORTANT: If OCmd_Stop is used
to stop the drive in a mode other
than Operator or Maintenance, a
reset is required before the drive can
be started.
Cfg_OperStopPrio
Allow local ‘Start’ or
‘Stop’ without
triggering alarm
Check (= 1) to let local circuits start/
stop the drive without an alarm.
Clear this checkbox (= 0) to
start/stop the drive from the HMI or
program only.
Cfg_AllowLocal
Time to ramp speed
feedback when in
Loopback Test
(seconds)
Enter the time, in seconds, to ramp
speed feedback when in Loopback
Test.
Cfg_SimRampT
Table 20 - Engineering Tab Page 4 Description
Function Action Security Configuration Parameters
To Next Page
